Fuji Ku

Fuji Ku Ceiling Acoustic Hero Image 1.jpg

Ku is the larger square-shaped, 3D formed acoustic tile in the Fuji range. Designed for sound absorption, Ku can be used as a conference table suspended feature, as well as large scale acoustic ceiling solutions for offices and commercial spaces.

Using the Array hardware, Fuji can be directly fixed to the ceiling or suspended in varying configurations of number, spacing, tile size, colourway (including dual colour), barrel kit and suspension height. Sustainably made using 64% recycled PET.

Colourways

908

299

420

550

Download Colourways

Order Sample

Product Specifications

Designer:

Woven Image

Dimensions:

Length: 840mm (+/- 3mm), Width: 840mm (+/- 3mm), Depth: 132mm (+/- 3mm), Thickness: 4.6 (+/- 2mm)

Composition:

Fuji Tile 100% PET (64% post-consumer recycled)

Fire Test Result:

BS EN 13501.1: Classification B - s1, d0
ISO 9705: Group 2
GB 8624 B1
ASTM E84 Unadhered: Class 1 or A

Sound Absorption Test Method:

AS ISO 354: 2006 (R2016)
AS ISO 11654: 2002 (2016)
ASTM C423 - 17

Equivalent Absorption Area (Aeq) in m² Sabins:

Without perimeter: 125Hz = 1.06m², 250Hz = 5.05m², 500Hz = 7.87m², 1000Hz = 7.58m², 2000Hz = 7.58m², 4000 = 8.74m²

Weighted Alpha Coefficient (αw):

With Perimeter: 0.80, Without Perimeter: 0.80

Sound Absorption Average (SAA):

With Perimeter: 0.74, Without Perimeter: 0.73

Noise Reduction Coefficient (NRC):

With Perimeter: 0.75, Without Perimeter: 0.70

Download Technical Reports Download Specification

Need more colour options? Fuji tiles are also available in any single or dual colour combination from our extensive Mura palette.

See specification for minimum order quantity.

Sustainability

Global GreenTag™ GreenRATE Level A

A third-party certification that assesses products’ ingredients, supply chain and manufacture for environmental, social and Building Code compliance. GreenRate Level A is a recognised initiative for Green Star Responsible Products credits.

Global GreenTag™ Product Health Declaration (PHD) - Platinum HealthRATE

A certification tool recognising full ingredient transparency, compliant with core WELL™ Features and LEED® Product Disclosure credits, that proves products are safe for human health.

Declare

A transparency initiative by the International Living Future Institute, Declare is an ingredients label for building products that enables design and build teams to make informed choices.

Red List Free

Products with the Red List Free label are complying with the Living Building Challenge goals of ingredient transparency and industry-wide elimination of all Red List chemicals.

Low VOC Emissions

Products with low volatile organic compounds (VOCs) are less harmful to the environment and human health and contribute to good Indoor Air Quality (IAQ).

Installation

Fuji Ceiling Tiles can be direct fixed or suspended using our Array hardware. The Fuji tiles attach to the hardware using our beautifully designed barrel kits which are available in three different colours (onyx, off-white and black/gold).

Refer to our Installation Guides and Video for detailed instructions or contact us for recommended installers.
