EchoPanel® Platoon
EchoPanel® Platoon free-standing acoustic screens are flexible partitions that divide spaces, whilst offering privacy and improved office acoustics.
Platoon comes flat packed with six pre-cut panels and cleverly designed pivot joiners, in cream or charcoal colourways. Pivot joiners allow for concertina opening at varying angles, and fold flat when not in use. Our free-standing screens are made of pinnable 24mm EchoPanel®, which achieves the highest Global GreenTag™ certification (GreenRate Level A) and Platinum Product Health Declaration, is Red-List free with low VOC (Volatile Organic Compound) emissions and has published ingredient transparency through Declare.
Colourways
454
442
542
Product Specifications
Designer:
Bang Design in collaboration with Woven Image
Dimensions:
Height: 1750mm (+/- 2mm), length: 3500mm (+/- 2mm), Thickness: 24mm (+/-7%)
Joiners are available in either Cream or Charcoal
Composition:
100% PET (60% post-consumer recycled)
Fire Test Result:
ISO 9705: Group 1
BS EN 13501.1: Classification B - s1, d0
ASTM E84 Adhered: Class 1 or A
Sound Absorption Test Method:
AS ISO 354: 2006 (R2016)
Weighted Alpha Coefficient (αw):
EchoPanel® 24mm achieves: Direct fix: 0.45 (MH), 20mm air gap: 0.50 (MH), 50mm air gap: 0.70 (MH)
Sound Absorption Average (SAA):
EchoPanel® 24mm achieves:
Direct fix: 0.63
Noise Reduction Coefficient (NRC):
EchoPanel® 24mm achieves:
Direct fix: 0.65, 20mm air gap: 0.75, 50mm air gap: 0.85
Sound Absorption Class:
D (Direct fix)
Additional Acoustic Information:
Sound Absorption Class result is based on EchoPanel® 24mm. MH = Mid to High Frequency
Sustainability
Low VOC Emissions
Products with low volatile organic compounds (VOCs) are less harmful to the environment and human health and contribute to good Indoor Air Quality (IAQ).
